Light Duty 98HP 4x2 ISUZU Tow Truck

Place of Origin China
Brand Name ISUZU
Certification CGC,ISO9001:2015,TUV SUD,PV,CNAS,
Model Number CL5053TQZD2
Minimum Order Quantity 1 UNIT
Price USD 26200- USD 28200/ UNIT
Delivery Time 45-60 work days

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Capacity Light Duty Material Steel
Color White Warranty 1 Year
Brakes Oil Brakes Engine Diesel
Exterior White Model ISUZU Tow Truck
Steering Power Suspension Leaf Spring
Wheelbase 3360 Mm
High Light

4x2 ISUZU Tow Truck

,

Light Duty ISUZU Tow Truck

,

Steel light duty tow truck

Leave a Message
Product Description

ISUZU 100P 98HP 4x2 Light Duty Wrecker Tow Truck

Overview:

The Wrecker Tow Truck is designed to provide reliable and efficient towing and recovery services for all kinds of vehicles. The fuel type is diesel and the tire type is all-terrain, which ensures better traction on any terrain. The body is made of high-grade steel for superior durability and performance. The truck is equipped with an ABS braking system to ensure safe braking in all conditions. This Rollback Tow Truck can be used for Auto Breakdown, Flatbed Tow Truck and other towing applications. Furthermore, the truck is suitable for long-distance transportation and tough towing jobs.

Light Duty 98HP 4x2 ISUZU Tow Truck 0Light Duty 98HP 4x2 ISUZU Tow Truck 1

Features:

1. With strong lifting arm and rear tow arm, it can easily towvehicles weight 4~8 tons;

2. 4-6 tons winch with 25m steel rope can help the vehicle moving to the rear of vehicle that the engine ofvehicle is broken Import hydraulic system, more reliable and stable;
3. Control levers on boths side of wrecker truck, you cancontrol it freely;
4. With one set of assist wheelers. When the wheel of cars broken, the assist wheelers can help the cars moving.

Light Duty 98HP 4x2 ISUZU Tow Truck 2

Technical Parameters:


Truck Specification
Cab 100P Single row Cabin with A/C, Power steering
Driving Type 4*2 left hand driving
Max Speed (km/h) 98
Overall dimension(mm) 6000*2090*2670
Mass in working order(kg) 4800
GVW(kg) 6275
Wheelbase(mm) 3815
Tire 6.50-16
Clutch Single-plate dry diaphragm spring clutch
Steering Hydraulic steering with power assistance
Gear box MSB 5-speed
Bridge Front axle 2.5T
Rear axle 3.5T
Engine Model 4JB1-CN
Fuel Type Diesel fuel
Type Water-cooled four-stroke, direct injection, turbocharged
Exhaust (ml) 2771
Max.output/ rotate speed(hp/rpm) 98/2900
Braking system Service Brake Compressed air brake
Park Brake Spring energy
Electric system 12v
Upper-Body specification
Hydraulic Under Lift at Rear
Fully Retracted Lifting weight(kg) 4000
Fully Extend Lifting Weight(kg) 2300
Max. Rated towing weight(kg) 6495
Max effective length of boom (mm) 1520
Extension traveling of boom (mm) 900
Boom structure
Maximum lifting height(mm) 3700
Fully Retracted Lifting weight(kg) 5000
Fully Extended Lifting weight(kg) 800
Extension traveling of hoisting boom(mm) 1540
Hydraulic winches & steel cables
Type: Planetary type
Quantity (set) 1
Max. Pulling power of winch (kgs) 5000
Length of steel cable(m) 15
Speed of winch (m/min) 3.23
Diameter of winch(cm) 11
Hydraulic Outriggers
Quantity 2
type in-built with power elevation &extension
Power take off
Type PTO drive from transmission
Wrecker Operation
Description Panel board comprising joysticks and hydraulic meters installed in a suitable place out of crew cabin.
Hydraulic System
Description Suitable capacity gear pumps for boom movement, telescoping cylinder, power steering and control valves & control system shall be with adequate size oil reservoir, integral oil cooler, valves etc.
Safety Device
Auto brake for winch Automatic safe brake in case winch / Engine fail.
Hydraulic valves Necessary hydraulic pressure relief & lock valve/ valves



Applications:

A Wrecker Tow Truck is a large and heavy-duty recovery vehicle with a high towing capacity and advanced safety features such as airbags and seatbelts. It is the perfect choice for those looking for a reliable and powerful wheel-lift tow truck or medium-duty tow truck. This truck is designed to meet the needs of commercial and industrial customers. It can easily tow large loads, even in difficult terrain or conditions. With its powerful towing power, it can quickly recover and move heavy vehicles and equipment. This makes it a great choice for any roadside assistance company or emergency service. It is also a great choice for those who are involved in construction or other large-scale projects.

 Light Duty 98HP 4x2 ISUZU Tow Truck 3

Customization:

Wrecker Tow Truck
 All kinds of wrecker trucks are available include flatbed wrecker, Integrated wrecker and Rotator wrecker from light duty to heavy duty. Also we can design customized wrecker superstructure parts according drawings.Light Duty 98HP 4x2 ISUZU Tow Truck 4

Support and Services:

Wrecker Tow Truck Technical Support and Service

1. Warranty
The customers can enjoy a maximum warranty period of 12 months or 10000 kilometers, whichever comes first, from shipment date on Bill of Lading.

2. Technical Support
For our supplied products, you can forever enjoy technical support whatever by phone call or email. We will respond aggressively to provide a prompt solution.

3. Onsite Training
On-site training could be executed if this term is included in the contracts agreed.

4. Onsite Service
We can assign our engineers to go to destination for on-site service if this term is included in the contracts agreed. Even service workshop could be built if the order comes to certain quantity.



Packing and Shipping:

For far away countries, We always use sea transport. According to vehicle dimension, we may use container vessel, or bulk vessel (the vehicle is lifted onto vessel by cranes), or RORO vessel (Roll on roll off vessel, the vehicle is driven on at loading port and driven off at discharge port, it is best way for a vehicle with engine. Semi-trailer without engine, can be loaded with a tractor from the port.) Usually it takes about 6 weeks to West Africa or South America. Shorter time to nearer countries.

Light Duty 98HP 4x2 ISUZU Tow Truck 5



FAQ:

1. Q: What is a Wrecker Tow Truck?

    A: A Wrecker Tow Truck is a heavy-duty vehicle used for towing or transporting goods from one place to another.



2Q: What are the features of a Wrecker Tow Truck?

    A: A Wrecker Tow Truck typically features a powerful engine, a large towing capacity, and a reinforced chassis for carrying heavy loads.



3. Q: What types of vehicles can be towed by a Wrecker Tow Truck?

    A: A Wrecker Tow Truck can tow most types of vehicles, including cars, trucks, vans, and SUVs.



4. Q: How much can a Wrecker Tow Truck tow?

    A: The towing capacity of a Wrecker Tow Truck depends on its size and engine power. Generally, they can tow up to 10 tons.



5. Q: Can a Wrecker Tow Truck be used for emergency situations?

    A: Yes, a Wrecker Tow Truck can be used for emergency situations such as accident recovery and rescuing vehicles that have become stranded on the side of the road.
